Overhead Line Construction Cable Stringing Equipment 40kn Hydraulic
Puller Tensioner for Transmision Line
Our MAR-YQZ40/MAR-YQZ60 Hydraulic Puller Tensioner offers a
versatile solution, capable of both pulling and tensioning
conductors, making it ideal for power line replacements. The
bullwheel is lined with wear-proof MC nylon segments for enhanced
durability.
This product features a unique closed-type hydraulic circuit and
bi-directional variable plunger pump, allowing for precise control
of tension force. Key components include the Rexroth pump and
motor, Italian RR reducer, and the model C attached reel winder.
Equipped with a spring-applied hydraulically released brake, our
MAR-YQZ40/MAR-YQZ60 ensures high reliability and ease of operation.
With a hydraulic power output interface, it can be seamlessly
integrated with the model DW2240A hydraulic conductor reel stand or
other compatible equipment.
Feature:
1. Our bull wheel features wear-resistant MC nylon lining segments
for enhanced durability.
2. Benefit from a closed hydraulic circuit and bi-directional
variable plunger pump for infinitely variable pull/tension control.
3. Equipped with top-notch components including Rexroth pump and
motor, Italian RR reducer, and model C attached reel winder.
4. Ensuring safety and ease of operation, our product includes a
spring-applied hydraulic release brake with overload protection.
5. Integrated with a dedicated hydraulic circuit for driving,
perfectly complemented by the DW2240A matched reel stand.
Product Table
| Order Number | 07223 | 07224 |
07228 |
| Model | MAR-YQZ40C | MAR-YQZ40D |
MAR-YQZ60 |
| Maximum Traction Force / Tension (kN) | 40/40 | 40/40 |
60/60 |
| Continuous Traction Force / Tension (kN) | 35/35 | 35/35 |
55/55 |
| Max. Pulling / Releasing Linespeed (km/h) | 5/5 | 5/5 |
5/5 |
| Bullwheel Bottom of Groove Diameter (mm) | Φ1200 | Φ1200 | φ1500 |
| Number of Bullwheel Grooves | 5 | 5 |
6 |
| Max. Diameter of Suitable Rope (mm) | Φ32 | Φ32 |
Φ40 |
| Engine | Model | Deutz F4L912(Germany ) | Cummins 4BT3.9 (DongFeng) | Deutz BF4L91 4 (Germany ) |
| Power (kW) | 51 | 60 |
82.5 |
| Speed (rpm) | 2500 | 2000 |
2500 |
| Weight (kg) | 3600 | 3200 |
4800 |
| Dimensions (mm) | 4170×1850×2400 | 3600×1850×2400 |
5520 × 1890 × 2400 |
Main Components
| Main Hydraulic Valve |
Rexroth |
| Radiator |
AKG |
| Hydraulic Instrument |
WIKA |
| Suitable Reel |
GSP1400 (Item Number: 07125C) |
Marshine Power provides a comprehensive range of OEM products
tailored to support transmission work worldwide. Our offerings
include Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope
Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, Cable Reel
Spools, and Stands. All products adhere to ISO 9001:2008 standards
and are distributed to over 50 countries.
We offer customization options for specialized items such as
emergency restoration towers and crossing structures. Additionally,
our safety tools and accessories have no minimum order quantity
requirements. Whether you require assistance with technical issues
or have specific product requirements, please feel free to contact
us. We are dedicated to providing tailored solutions to meet your
transmission needs effectively. Thank you for considering Marshine
Power as your partner in transmission projects.
