Four Gear Hydraulic Tractor Winch
Application:
Our Fast Speed Double Drum Winch Tractor is specifically designed for pulling and lifting operations during tower erection, making it ideal for handling no-twist wire ropes.
Key Features:
1. Equipped with four gears, including forward and reverse gears,
offering enhanced versatility in operation.
2. Features a double drum with seven grooves, ensuring the wire
rope is protected efficiently while providing speed and
convenience.
3. The walking tractor's grinding mechanism has been upgraded from
the 12-type walking tractor, enhancing overall performance and
reliability.
Technical Data
Item number | Model | Ground | wheel-base(MM) | Power(HP) | speed(RPM) | Travel speed(KM/H) | Outline |
Clearance(MM) | size(MM) | ||||||
9171 | 12-A | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 |
9172 | 12-B | 150 | 1040 | 15 | 2000 | 3-13 | 2670x1040x1300 |
Gear | 1 | 2 | 3 | 4 | reversal 1 | reversal 2 | |
Traction force(T) | 60 | 37 | 20 | 12 | / | / | |
Traction speed(M/MN) | 11.7 | 18.9 | 34.4 | 55.6 | 6.2 | 21.3 |
Marshine Power stands ready to bolster transmission work with our comprehensive lineup of OEM products, including Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, and Cable Reel Spools and Stands. All items are crafted to meet ISO 9001:2008 standards, ensuring professional quality. With a presence in over 50 countries worldwide, our products are trusted by professionals globally. Customization options are available for specialized needs like emergency restoration towers and crossing structures. Additionally, our safety tools and accessories come with flexible order quantities, catering to your specific requirements. Whether you need technical assistance or have product inquiries, don't hesitate to reach out to us. We're here to help. Thank you.
![]() |
