    Diesel Engine Overhead Wire Hydraulic Cable Tensioner for Transmission Line

    Ask Lasest Price
    Brand Name : MARSHINE
    Certification : CE, ISO
    Delivery Time : 15-30DAY
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100 Sets Per Month
    Model Number : MAR-YZ2×40B
    Price : US$10000-US$100000
    • Product Details
    • Company Profile

    Diesel Engine Overhead Wire Hydraulic Cable Tensioner for Transmission Line

    Transmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic Tensioner with 80kn Capacity

    Product Description

    Our MAR-YZ2×40B Hydraulic Tensioner is designed for stringing various types of conductors and earth wires, offering the flexibility of one-pull-one or one-pull-two options.

    Featuring an infinitely variable tension control system, this tensioner ensures consistent tension during conductor stringing operations. In the event of hydraulic failure, the spring-applied hydraulically released multi-plate brake engages automatically, ensuring secure operation.

    Additionally, our product comes equipped with two sets of hydraulic power output interfaces, allowing for connection to hydraulic conductor reel stands. The bullwheel is lined with wear-resistant MC nylon material for enhanced durability.

    This tensioner is suitable for stringing both single conductors and bundled conductors, making it versatile for various applications in transmission work.


    Product Parameters

    Essential Parameters

    Model
    MAR-YZ2*40B Hydraulic Tensioner
    Maximum Tension (kN)
    2× 40 or 1× 80
    Continuous Tension (kN)
    2× 35 or 1× 70
    Maximum Speed (km/h)
    5
    Bullwheel Bottom of Groove Diameter (mm)
    Φ1500
    Number of Grooves
    2× 5
    Maximum Pullback (kN)
    2× 40 or 1× 80
    Maximum Speedback (km/h)
    2× 1.5
    Maximum Diameter of Suitable Conductor (mm)
    Φ40
    Engine Power / Speed (kW/rpm)
    51/2500
    Dimensions (mm)
    4500 × 2200 × 2800
    Weight (kg)
    4850

    Main Components
    Engine
    Beinei Deutz air cooled diesel engine
    Main Pump/MotorRexroth
    Reducer
    RR (Italian)
    Main Hydraulic ValveRexroth
    Radiator
    AKG
    Hydraulic InstrumentWIKA
    Option
    If use Deutz (Germany) diesel engine,the model is MAR-YZ2×40A,item number:07191
    Others
    According to customer requirement, our MAR-YZ2×40B Hydraulic Tensioner can configure mobile control consoles. It is easy for one operator to control 2 machines simultaneously, which facilitates 4-conductor-stringing operation using two machines. The item number of control consoles is 07193.
    Transmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic Tensioner

    To facilitate transmission work, Marshine Power offers a comprehensive range of OEM equipment, including Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, Cable Reel Spools, and Stands. All our products adhere to ISO 9001:2008 standards and are distributed to over 50 countries globally.

    We provide customization options for items such as emergency restoration towers and crossing structures, and there's no Minimum Order Quantity (MOQ) requirement for safety tools and accessories. Whether you need technical assistance or have specific product requirements, feel free to reach out to us for support. We're here to help. Thank you.

    Transmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic Tensioner
    Transmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic TensionerTransmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic Tensioner
    FAQ



    1. Training and services.
    Marshine is a company specializing in the development, design and manufacture of electrical construction equipment and tools. We not only manufacture and sell international standard products, OEM and custom products, but also provide quality tracking and service monitoring.

    2. How about the quality of your products?
    Our products are manufactured in strict accordance with national and international standards, and each product is tested before delivery. If you would like to view our quality certification and various test reports, please consult us.

    3. Why do you choose us?
    Because we can provide you with excellent service, quality and reasonable price. In addition, we can also provide smooth delivery of goods, excellent customer solutions.

    4. Customer inquiry.
    If there is an emergency, customers can also use online contact methods (online Chat, Skype, WhatsApp, wechat) for faster and better communication. Any enquiry will be answered within 12 working hours.

    5. How to obtain samples?
    We can provide free samples to the buyer for testing, but the buyer needs to pay the freight. Existing samples take 2-3 days. If there is no stock, we will advise the delivery date.

    6. How about packing and shipping?
    All goods will be packed in plywood boxes for safe, long haul transport. Support EXW, FOB, CIF, CFR terms.
    Required documents such as packing list, commercial invoice, bill of lading, air waybill, CO, Form E, Form F etc will be provided.


    Note: If you do not find the product you need, please feel free to contact us. We will provide the best quotation as soon as we verify your requirements.
